Technical Data
| Design | Special Sure Grip TD9 |
|---|---|
| Industry Classification | R2 |
| Tyre size | 480/80R42 |
| LI/SS | 151A8 |
| FR/DW | |
| PR | |
| TL/TT | |
| Tyre Width (mm) | 466 |
| Overall diameter (mm) | 1901 |
| Static Loaded radius (mm) | 857 |
|---|---|
| Rolling circumference (mm) | 5739 |
| SRI | 900 |
| Weight (kg) | 192 |
| Nominal Inflation Pressure (bar) | 1.6 |
| Maximum Load (kg) | 3447 |
| Tread Depth (mm) | 73 |
| Recom 'd Rim Width | |
| Other approved rims | W16A,DD16,DW16A |
Load Data
Max Speed (Km/h)
40
30
25
15
10 cycl
10
Type load (kg) at various inflation pressures (kPa)
60kPa
40 km/h
1850
30 km/h
2070
25 km/h
2200
15 km/h
2440
10 cycl km/h
10 km/h
2925
80kPa
40 km/h
2180
30 km/h
2440
25 km/h
2595
15 km/h
2880
10 cycl km/h
10 km/h
3445
100kPa
40 km/h
2500
30 km/h
2800
25 km/h
2975
15 km/h
3300
10 cycl km/h
3145
10 km/h
3950
120kPa
40 km/h
2800
30 km/h
3135
25 km/h
3330
15 km/h
3695
10 cycl km/h
3705
10 km/h
4425
140kPa
40 km/h
3150
30 km/h
3530
25 km/h
3750
15 km/h
4160
10 cycl km/h
4250
10 km/h
4975
160kPa
40 km/h
3450*
30 km/h
3865
25 km/h
4105
15 km/h
4555
10 cycl km/h
4760
10 km/h
5450
180kPa
40 km/h
30 km/h
25 km/h
15 km/h
10 cycl km/h
5355
10 km/h
*Maximum load at recommended speed and inflation pressure.
